The electric stacker forklift is one of the most versatile and efficient materials handling equipment available today. It is capable of moving heavy loads with ease, in tight spaces, and at a fraction of the cost of traditional methods. With its easy-to-use design and safety features, the electric stacker forklift can be a great asset for any business or warehouse. 1.5 ton electric walkie stacker forklift for sale is a popular model in the market.
1.5 ton electric walkie stacker specification
|Product Model||CDD 15Y|
|Driving Style||Stand and Drive Type|
|Self Weight(with battery)||kg||680|
|Drive Wheel size(diameter*width)||mm||φ210*70|
|Front Wheel size(diameter*width)||mm||φ80*70|
|Balance Wheel size(diameter*width)||mm||125*50|
|Overall Height(Min height)||mm||2080/1580/1830/2080/2330|
|Overall Height(Lift height)||mm||2080/2560/3060/3560/4060|
|Operation Handle Height above Ground(max/min)||mm||1520/1050|
|Overall Length(Stand up/down)||mm||2023/2419|
|Outer Width of Fork||mm||680|
|Aisel Width,1000*1200pallet lengthwise stand up/down||mm||2879|
|Turning Radius(Pedal up)||mm||1619|
|Travel Speed(empty/no load)||km/h||4/5|
|Max climbing ability(no load)||mm/s||100|
|Max climbing ability(empty load)||mm/s||50|
|Max climbing ability(empty/no load)||%||3/5|
|Service Brake||Electromagnetic brake|
|Drive Motor Rating||kw||DC0.75|
|Lifting Motor Rating||kw||DC2.2|
|Battery Voltage/Rated Capacity||a/ah||2*12v/120ah|
One of the greatest advantages of the electric stacker forklift is its ability to maneuver in tight spaces. This is due to its low profile design and narrow turning radius. This makes it ideal for working in small areas, such as in warehouses and loading docks.
The electric pallet stacker is also extremely safe to operate. It has an emergency stop button that immediately stops the lift in case of an accident or malfunction.
Finally, the electric stacker forklift is highly cost effective. It requires minimal maintenance, runs on rechargeable batteries, and offers maximum efficiency for a relatively low price. Overall, the electric stacker forklift is an ideal tool for businesses and warehouses that need to move materials quickly and safely. With its versatility and ease-of-use, it can be a great asset for any business or warehouse.
