China Full Electric Stacker 2 ton for sale

Short Description:

Product Name: Full Electric Stacker

Capacity: 2 ton/2000 kg

Power Type: Electric

Origin: China

For electric stacker price, customization, or other inquiries, get in touch with our team.



China full electric stacker 2 ton for sale. The electric pallet stacker is an ideal choice for the medium stacking operations. This 2 ton electric walkie stacker is with compacted chassis, lightweight, smaller turning radius which can be more flexible and useful in material handling and logistic transportation.

full electric stacker

2 ton Electric stacker dimensions

Product ModelCDD 20Y
Drive TypeElectric
Driving StyleStand and Drive Type
Load Capacitykg2000
Load Centermm500
Self Weight(with battery)kg680
Tyrepolyurethane wheels
Drive Wheel size(diameter*width)mmφ250*80
Front Wheel size(diameter*width)mmφ80*70
Balance Wheel size(diameter*width)mm125*40
Wheel number(X-Driven)1x=2/4
Front Wheelbasemm500
Rear Wheelbase616
Overall Height(Min height)mm2080/1580/1830/2080/2330
Overall Height(Lift height)mm2080/2560/3060/3560/4060
Lift Heightmm1600/2000/2500/3000/3500
Min Heightmm≦90
Operation Handle Height above Ground(max/min)mm1520/1050
Overall Length(Stand up/down)mm2030/2419
Overall Widthmm850
Fork Sizemm170/55/1150
Outer Width of Forkmm680
Min Heightmm30
Aisel Width,1000*1200pallet lengthwise stand up/downmm2879
Turning Radius(Pedal up)mm1619
Travel Speed(empty/no load)km/h4/5
Max climbing ability(no load)mm/s100
Max climbing ability(empty load)mm/s50
Max climbing ability(empty/no load)%3/5
Service BrakeElectromagnetic brake
Drive Motor RatingkwDC1.5
Lifting Motor RatingkwDC2.2
Battery Voltage/Rated Capacitya/ah2*12v/120ah

Electric Pallet Stacker Features

1. Electric walking & lifting.

2. The mast is made of imported steel or custom-made manganese steel, so that the body will never be deformed and durable.

3. The electronic control system of the original joint venture brand is sensitive in response and safe in operation.

4. The drive assembly imported from Italy is powerful.

5. Combination of large-capacity traction battery makes the continuous working time longer.

6. The intelligent charger guarantees the service life of the battery.

electric walkie stacker for sale

Applications of electric pallet truck

This electric walkie reach stackers are widely used in factory workshops, warehouses, distribution centers and distribution centers, ports, stations, airports, freight yards, etc., and can enter cabins, carriages and containers for loading, unloading and handling of palletized goods. It is an essential equipment for pallet transportation and container transportation.

About Dogon Forklift

Dogon (China) Group is specializing in the design, development and production of forklift trucks, as well as a long-term exporter of high-quality material  handling equipment products to countries around the world.

The main products include diesel forklift trucks, electric forklift trucks, pallet stackers, pallet jacks, engineering telehandler trucks, articulating boom lift, hydraulic scissor lift platform and other material handling equipment.
